Videowall - Vh55c - 55in Vhc-e Extreme Narrow Bezel

Display

Display technology

LCD

Display diagonal

139.7 cm (55")

Display resolution

1920 x 1080 pixels

HD type

Full HD

Panel type

IPS

Aspect ratio

16:9

Pixel pitch

0.63 x 0.63 mm

Display brightness

700 cd/m²

Pixel frequency

78 MHz

Contrast ratio (typical)

1000:1

Contrast ratio (dynamic)

140000:1

Response time

0.008 s

Viewing angle, horizontal

178°

Viewing angle, vertical

178°

Horizontal scan range

57.3 - 70 kHz

Vertical scan range

47 - 63 Hz

Haze rate

28%

Colour gamut

72%

Operating hours (hours/days)

24/7

Display diagonal (metric)

138 cm

Design

Placement supported

Indoor

Orientation

Landscape/Portrait

Bezel colour

Black

Wall mountable

Yes

VESA mounting

Yes

Panel mounting interface

600 x 400 mm

Product colour

Black

Ports & interfaces

HDMI ports quantity

2

HDMI version

2.0

DVI port

Yes

DVI-D ports quantity

1

DisplayPorts quantity

1

DisplayPort version

1.2

Ethernet LAN

Yes

Ethernet LAN (RJ-45) ports

1

RS-232 input ports

1

RS-232 output ports

1

USB port

Yes

HDCP

Yes

HDCP version

2.2

IR input ports quantity

1

Audio input

Yes

Audio output

Yes

Video out

Yes

Power

Power consumption (typical)

250 W

Power consumption (sleep)

0.5 W

Energy efficiency scale

A to G

Energy efficiency class (SDR)

G

Energy consumption (SDR) per 1000 hours

145 kWh

AC input voltage

100 - 240 V

AC input frequency

50/60 Hz

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

10 - 90%

Technical details

Compliance certificates

CB, Federal Communications Commission (FCC)

Sustainability

Sustainability compliance

Yes

Certification

FCC (USA) Part 15, Subpart B Class B CE (Europe) : EN 55032:2015+A11:2020 / EN 55035:2017+A11:2020 / EN IEC 61000-3-2:2019 / EN 61000-3-3:2013+A1:2019 VCCI (Japan) : VCCI-CISPR32 : 2015 KC (Korea) : KS C 9832 / KS C 9835 RCM (Australia/ Newzealand) : AS/N CB (Europe) : IEC62368-1/EN62368-1 CCC (China) : GB 4943.1-2011 (Singapore ) : PSB+IEC62368-1NOM (Mexico ) : Tunerless : NOM-019-SCFI-1998IRAM (Argentina ) : IRAM+IEC62368-1 SIRC (Saudi Arabia ) : SASO+IEC62368-1 BIS (India) : IEC60950-1 / IS13252KC (Kore

Weight & dimensions

Width

1212.2 mm

Depth

70.4 mm

Height

683 mm

Weight

19.5 kg

Packaging data

Package width

1398 mm

Package depth

257 mm

Package height

844 mm

Package weight

27.1 kg
