Introduction
Intel® Gaussian & Neural Accelerator
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.
Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.
Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.
Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.
Intel® Standard Manageability (ISM)
Intel® Standard Manageability is the manageability solution for Intel vPro® Essentials platforms and is a subset of Intel® AMT with out-of-band management over Ethernet and Wi-Fi, but no KVM or new life cycle management features.
Intel® Control-Flow Enforcement Technology
CET - Intel Control-flow Enforcement Technology (CET) helps protect against the misuse of legitimate code snippets through return-oriented programming (ROP) control-flow hijacking attacks.
Processor
Bus type
DMI4
Memory bandwidth supported by processor (max)
76.8 GB/s
Processor manufacturer
Intel
Processor generation
Intel Core i3-13xxx
Processor model
i3-13100
Processor family
Intel® Core™ i3
Processor cores
4
Processor socket
LGA 1700
Processor threads
8
Processor operating modes
64-bit
Performance cores
4
Processor boost frequency
4.5 GHz
Performance-core boost frequency
4.5 GHz
Performance-core base frequency
3.4 GHz
Processor cache
12 MB
Processor cache type
Smart Cache
Box
N
Processor base power
60 W
Maximum turbo power
89 W
Maximum number of DMI lanes
8
Processor codename
Raptor Lake
Processor ARK ID
230575
Features
Thermal solution specification
PCG 2020C
Execute Disable Bit
Y
Idle States
Y
Thermal Monitoring Technologies
Y
Market segment
Desktop
Use conditions
PC/Client/Tablet
Maximum number of PCI Express lanes
20
PCI Express slots version
4.0, 5.0
PCI Express configurations
1x16+1x4, 2x8+1x4
Supported instruction sets
AVX 2.0, SSE4.1, SSE4.2
Scalability
1S
CPU configuration (max)
1
Embedded options available
Y
Direct Media Interface (DMI) Revision
4.0
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
740.17B1
Processor special features
Intel Enhanced Halt State
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Y
Intel® Turbo Boost Technology
2.0
Intel® Quick Sync Video Technology
Y
Intel® Clear Video HD Technology (Intel® CVT HD)
Y
Intel® AES New Instructions (Intel® AES-NI)
Y
Enhanced Intel SpeedStep Technology
Y
Intel® Speed Shift Technology
Y
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Y
Intel® Control-flow Enforcement Technology (CET)
Y
Intel® Thread Director
N
Intel VT-x with Extended Page Tables (EPT)
Y
Intel® Secure Key
Y
Intel® OS Guard
Y
Intel 64
Y
Intel Virtualization Technology (VT-x)
Y
Intel Virtualization Technology for Directed I/O (VT-d)
Y
Intel Turbo Boost Max Technology 3.0
N
Intel® Boot Guard
Y
Intel® Deep Learning Boost (Intel® DL Boost)
Y
Intel® Volume Management Device (VMD)
Y
Mode-based Execute Control (MBE)
Y
Intel® Standard Manageability (ISM)
Y
Intel® Threat Detection Technology (TDT)
Y
Technical details
OpenGL support
Yes
Status
Launched
OpenCL version
3.0
Launch date
Q1'23
Packaging data
Package type
Tray
Other features
Maximum internal memory
192 GB
L2 cache
5120 KB
Graphics output
eDP 1.4b, DP 1.4a, HDMI 2.1
Memory
Maximum internal memory supported by processor
128 GB
Memory types supported by processor
DDR4-SDRAM, DDR5-SDRAM
Memory channels
Dual-channel
Memory bandwidth (max)
76.8 GB/s
Graphics
On-board graphics card
Y
Discrete graphics card
N
On-board graphics card model
Intel UHD Graphics 730
On-board graphics card outputs supported
Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card base frequency
300 MHz
On-board graphics card dynamic frequency (max)
1500 MHz
Number of displays supported (on-board graphics)
4
On-board graphics card DirectX version
12.0
On-board graphics card OpenGL version
4.5
On-board graphics card maximum resolution (DisplayPort)
7680 x 4320 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)
5120 x 3200 pixels
On-board graphics card maximum resolution (HDMI)
4096 x 2160 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort)
60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)
60 Hz
On-board graphics card ID
0x4692
Discrete graphics card model
Not available
Number of execution units
24
Multi-Format Codec Engines
1
Operational conditions
Tjunction
100 °C
Logistics data
Harmonized System (HS) code
8542310001
Weight & dimensions
Processor package size
45 x 37.5 mm
