Introduction
The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.
Processor
Processor manufacturer
Intel
Processor generation
3rd Generation Intel® Xeon® Scalable
Processor model
5317
Processor base frequency
3 GHz
Processor family
Intel® Xeon® Gold
Processor cores
12
Processor socket
LGA 4189
Component for
Server/workstation
Processor lithography
10 nm
Processor series
Intel Xeon Gold 5000 Series
Processor threads
24
System bus rate
11.2 GT/s
Processor operating modes
64-bit
Processor boost frequency
3.6 GHz
High priority cores
4
High priority core frequency
3.2 GHz
Low priority cores
8
Low priority core frequency
2.8 GHz
Processor cache
18 MB
Thermal Design Power (TDP)
150 W
Box
No
Cooler included
No
Processor codename
Ice Lake
Processor ARK ID
215272
Memory
Maximum internal memory supported by processor
6 TB
Memory types supported by processor
DDR4-SDRAM
Memory channels
Octa-channel
ECC
Yes
Graphics
On-board graphics card
No
Discrete graphics card
No
On-board graphics card model
Not available
Discrete graphics card model
Not available
Features
Execute Disable Bit
Yes
Market segment
Server
Maximum number of PCI Express lanes
64
PCI Express slots version
4.0
Supported instruction sets
SSE4.2, AVX, AVX 2.0, AVX-512
Scalability
2S
Embedded options available
Yes
Export Control Classification Number (ECCN)
5A992CN3
Commodity Classification Automated Tracking System (CCATS)
G178966
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Turbo Boost Technology
2.0
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel Trusted Execution Technology
Yes
Intel® Speed Shift Technology
Yes
Intel® Transactional Synchronization Extensions
Yes
Intel® Total Memory Encryption
Yes
Intel® Crypto Acceleration
Yes
Intel® Platform Firmware Resilience Support
Yes
Maximum Enclave Size Support for Intel® SGX
64 GB
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel Software Guard Extensions (Intel SGX)
Yes
Intel 64
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
AVX-512 Fused Multiply-Add (FMA) units
2
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Intel® Resource Director Technology (Intel® RDT)
Yes
Intel® Volume Management Device (VMD)
Yes
Intel® Run Sure Technology
Yes
Mode-based Execute Control (MBE)
Yes
Intel® Optane™ DC Persistent Memory Supported
Yes
Operational conditions
Tcase
84 °C
Technical details
Target market
Cloud Computing
Launch date
Q2'21
Status
Launched
Supported memory types
DDR4-SDRAM
Memory speed (max)
2933 MHz
Number of UPI links
3
Servicing status
Baseline Servicing
Logistics data
Harmonized System (HS) code
85423119
Other features
Maximum internal memory
6 TB
