Design
Product colour
Grey
Form factor
Tower
Display type
LCD
International Protection (IP) code
IP31
Technical details
Compliance certificates
CE, RoHS
Sustainability compliance
Yes
Features
Output power capacity
80 kVA
Output power
64000 W
Waveform
Sine
Input operation voltage (min)
380 V
Input operation voltage (max)
415 V
Input frequency
45/55 Hz
Output operation voltage (max)
384 V
Number of input phases
3
Number of output phases
1
Output voltage Total Harmonic Distortion (THD)
2%
Noise level
70 dB
Audible alarm(s)
Yes
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-25 - 55 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 2000 m
Non-operating altitude
0 - 10000 m
Weight & dimensions
Width
800 mm
Depth
800 mm
Height
1800 mm
Weight
724 kg
Package width
928 mm
Package depth
928 mm
Package height
2085 mm
Package weight
798 kg
