Introduction
USB connection
Use your PC to access additional power protection and management features for your UPS via a USB Port.
Automatic Voltage Regulation (AVR)
Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment.
Features
UPS topology
Line-Interactive
Output power capacity
0.7 kVA
Output power
390 W
Waveform
Sine
Input operation voltage (min)
140 V
Input operation voltage (max)
300 V
Input frequency
50/60 Hz
Output frequency regulation
50/60 Hz
Automatic Voltage Regulation (AVR)
Y
Surge energy rating
273 J
Hold time (max)
4 ms
Efficiency
96.6%
Noise level
45 dB
Audible alarm(s)
Y
Audible alarm modes
Low battery alarm, Overload alarm
Ports & interfaces
AC outlet types
Type F
AC outlets quantity
4 AC outlet(s)
Number of type F outputs
4
USB port
Y
Battery
Battery technology
Sealed Lead Acid (VRLA)
Battery capacity
7.2 Ah
Battery capacity
81 VAh
Battery voltage
12 V
Typical backup time at full load
1.3 min
Typical backup time at half load
8.7 min
Battery life (max)
5 year(s)
Battery recharge time
6 h
Automatic battery test
Y
Design
Form factor
Tower
Cable length
1.52 m
Product colour
Black
LED indicators
Battery replacement
Certification
REACH
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-15 - 40 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Non-operating altitude
0 - 9000 m
Technical details
Sustainability certificates
RoHS
Weight & dimensions
Width
115 mm
Depth
256 mm
Height
200 mm
Weight
6 kg
Package width
295 mm
Package depth
340 mm
Package height
275 mm
Package weight
6.4 kg
Packaging data
Manual
Y
Bundled software
PowerChute Personal Edition
Other features
Nominal output voltage
230 V
Nominal input voltage
230 V
